STANDART VERSION (CLINIC 3/40)
Technical Data
· Condensate Treatment: -
· Particulate Treatment: -
· Air purity class (ISO 8573-1): X-X-0
· Voltage (V): 230,00
· Frequency (Hz): 50,00
· Nominal rating (kW): 1,80
· Nominal rating (HP): 2,50
· Rotation speed (rpm): 1.400,00
· Absorption (A): 8,00
· Number of cylinders: 2
· Air intake (L/min): 240,00
· Air Delivery (L/min @5 bar): 155,00
· Air Delivery (L/min @8 bar): 125,00
· Maximum pressure (bar): 10,00
· Noise level (3,00m @ 5,00 bar (dB(A))): 67,00
· Duty cycle: S1 100%
· Tank Coating: Acciaio Inox AISI 304
· Tank capacity (lt): 40,00
· First Maintenance (hours): 3000
· Hour Meter: Incluso
· Tank Automatic Drain kit: Optional
Product Dimensions
· Dimensions (cm) - LxWxH: 65,2x46,3x65,2
· Weight (Kg): 39
VERSION WITH MEMBRANE DRYER (CLINIC DRY 3/40 H)
Technical Data
· Condensate Treatment: Membrane air dryer | Dew point -40°C
· Particulate Treatment: 0,3 µm
· Air purity class (ISO 8573-1): 3-3-0
· Voltage (V): 230,00
· Frequency (Hz): 50,00
· Nominal rating (kW): 1,80
· Nominal rating (HP): 2,50
· Rotation speed (rpm): 1.430,00
· Absorption (A): 8,00
· Number of cylinders: 2
· Air intake (L/min): 240,00
· Air Delivery (L/min @5 bar): 120,00
· Air Delivery (L/min @8 bar): 80,00
· Maximum pressure (bar): 10,00
· Noise level (3,00m @ 5,00 bar (dB(A))): 67,00
· Duty cycle: S1 100%
· Tank Coating: Acciaio Inox AISI 304
· Tank capacity (lt): 40
· First Maintenance (hours): 3000
· Hour Meter: Incluso
· Tank Automatic Drain kit: Optional
Product Dimensions
· Dimensions (cm) - LxWxH: 65,2x46,3x65,2
· Weight (Kg): 42
VERSION WITH MEMBRANE AND STERILIZING FILTER (CLINIC DRY 3/40 HS)
Technical Data
· Condensate Treatment: Membrane air dryer | Dew point -40°C
· Particulate Treatment: 0,3 µm
· Air purity class (ISO 8573-1): 3-3-0
· Voltage (V): 230,00
· Frequency (Hz): 50,00
· Nominal rating (kW): 1,80
· Nominal rating (HP): 2,50
· Rotation speed (rpm): 1.430,00
· Absorption (A): 8,00
· Number of cylinders: 2
· Air intake (L/min) : 240,00
· Air Delivery (L/min @5 bar): 120,00
· Air Delivery (L/min @8 bar): 80,00
· Maximum pressure (bar): 10,00
· Noise level (3,00m @ 5,00 bar (dB(A))): 67,00
· Duty cycle: S1 100%
· Tank Coating: Acciaio Inox AISI 304
· Tank capacity (lt): 40
· First Maintenance (hours): 3000
· Hour Meter: Incluso
· Tank Automatic Drain kit: Optional
Product Dimensions
· Dimensions (cm) - LxWxH: 65,2x46,3x65,2
· Weight (Kg): 42
